Ladder Cable Tray Outside Riser 45
Product Details:
- Max. Working Load Up to 85 kg/m (depending on tray size and material)
- Conductor Material NA (Non-conductive hardware; intended for cable support, not conduction)
- Deflection Within IEC/IS standards (<10mm at rated load)
- Surface Finish Pre-Galvanized / Hot Dip Galvanized / Powder Coated / Painted
- Product Type Ladder Cable Tray Outside Riser 45
- Material Mild Steel / Stainless Steel / Aluminum
- Standard Thickness 1.6 mm / 2 mm / 2.5 mm / 3 mm
- Click to View more
X
Ladder Cable Tray Outside Riser 45 Product Specifications
- Ladder Cable Tray Outside Riser 45
- Varies according to size and material
- Galvanized / Silver / Custom Color Option
- 2500 mm x (1001200) mm x (50150) mm
- 1.6 mm / 2 mm / 2.5 mm / 3 mm
- Up to 85 kg/m (depending on tray size and material)
- NA (Non-conductive hardware; intended for cable support, not conduction)
- Within IEC/IS standards (<10mm at rated load)
- 2500 mm
- Pre-Galvanized / Hot Dip Galvanized / Powder Coated / Painted
- Mild Steel / Stainless Steel / Aluminum
- 100 mm - 1200 mm (customizable)
- 50 mm - 150 mm
Product Description
SpecificationRadius (mm) | 300, 600, 800, 900, |
1000, 1200 | |
Width (mm) | 100 - 1500 |
Channel Dimension (mm | 50 x 15 x 15 |
50 x 20 x 20 | |
75 x 15 x 15 | |
75 x 20 x 20 | |
100 x 15 x 15 | |
100 x 20 x 20 | |
100 x 25 x 25 | |
125 x 25 x 25 | |
150 x 25 x 25 | |
Rung Dimension (mm) | 30 x 15 x 15 |
35 x 15 x 15 | |
40 x 15 x 15 | |
40 x 20 x 20 | |
50 x 15 x 15 | |
50 x 20 x 20 | |
50 x 25 x 25 | |
Thickness (mm) | 1.2 - 3 |
Product Name | Ladder Tray Vertical-Bend-Outside |
Brand Name | SUPERFAB INC. |
Model Number | 75 |
Size | Customizable |
Type | For Security Guard |
Material | Find with various materials |
Design | Special & various design available (Customizable) |
Coating | According to customer |
Certification | certified |
FOB Price | Sent by mail |
Main Markets | Domestic and International Market |
Minimum Order Quantity | As per requirement |
Place of Origin | Mumbai, Maharashtra, India |
Efficient Cable Route Turns
The Ladder Cable Tray Outside Riser 45 streamlines cable transitions at 45-degree angles, supporting neat and secure cable management in demanding applications. Ideal for corners and direction changes, its robust structure maintains support and organization for varied cable loads. Customizable width, side rail height, and rung spacing accommodate diverse project requirements, ensuring flexibility and precise fit.
Optimized Ventilation and Safety
Open rung spacing in this ladder tray design promotes airflow, helping to keep cables cool under load. Enhanced fire resistancedependent on chosen materialadds an extra layer of operational safety. Corrosion-resistant finishes, including galvanized and powder-coated options, further bolster its longevity and reliability in harsh environments.
Simple and Adaptable Installation
Installation is straightforward with bolted splice plates and available accessories such as covers, couplers, and clamps. Whether wall mounted or free standing, the tray provides versatility for electricians and facility managers. Customizable dimensions and finishes allow seamless integration into any cable routing plan.
FAQs of Ladder Cable Tray Outside Riser 45:
Q: How is the Ladder Cable Tray Outside Riser 45 installed?
A: The tray can be mounted directly to walls or used as a free-standing system. Connection is made with bolted splice plates and compatible accessories such as clamps and couplers. Installation is designed for straightforward, secure assembly.Q: What are the standard and customizable options for rung spacing and size?
A: The tray comes with standard rung spacing of 250 mm, but can be customized to meet specific project needs. Length is typically 2500 mm, while width varies from 100 mm to 1200 mm. Custom dimensions are available upon request.Q: When should I use the 45-degree outside riser ladder cable tray?
A: This tray is best suited for applications where cable routes require a smooth 45-degree turn, such as in commercial and industrial plants where precise cable management is crucial for system reliability and safety.Q: Where is the Ladder Cable Tray Outside Riser 45 typically used?
A: It is ideal for use in industrial and commercial settingssuch as factories, power plants, and data centerswhere structured cable routing and safe direction changes are necessary.Q: What process ensures the trays corrosion resistance and fire safety?
A: Corrosion resistance is achieved through finishes like pre-galvanization, hot dip galvanization, or powder coating. Fire resistance depends on the chosen material and conforms to IEC 61537 and IS 6746 standards for enhanced safety.Q: Can the products dimensions, finish, and material be customized for my application?
A: Yes, the trays size, finish, rung spacing, and material can be tailored to project specifications, ensuring compatibility with unique cable management needs.Q: What benefits does using an outside riser cable tray provide?
A: It enables efficient cable routing around 45-degree turns, promotes airflow, enhances fire protection, and offers corrosion resistance, contributing to long-term system reliability and safety.Tell us about your requirement
